Hydro Dryer Machine
Big Size Tilting Hydro Dryer (Centrifugal De-Oiler) with a 20 x 20 inch
drum is a high-capacity industrial machine used to remove excess oil from fried
snacks (Namkeen, Chips, Fryums) or water from washed vegetables.
For a 20-inch drum, the "Tilting" feature is essential because
a full load (approx. 20–25 kg) is too heavy to lift manually.
1. Technical Specifications (20" x 20" Industrial Model)
|
Feature |
Details |
|
Drum Size |
20 inch Diameter x 20 inch Height (Approx. 100-liter volume) |
|
Batch Capacity |
20 to 30 kg per batch (depending on product density) |
|
Production Rate |
300 to 500 kg/hr (Continuous batch processing) |
|
Material |
Full SS 304 Food Grade (Inner basket & Outer body) |
|
Motor Power |
2 HP to 3 HP (High Torque) |
|
RPM |
700 to 900 RPM (Variable speed via VFD recommended) |
|
Tilting Mechanism |
Manual Gear-Hand or Pneumatic Cylinder |
2. Key Design Features
- Tilting
System: Equipped with a heavy-duty Worm & Wheel Gearbox. You simply
rotate a handle, and the entire drum tilts 180° to discharge the product
directly into a flavoring drum or trolley.
- Self-Balancing
Basket: At 20 inches, vibration can be an issue. High-end models in
Ahmedabad feature a 3-point suspension or a precision-balanced shaft to
ensure "zero-vibration" operation.
- Safety
Brake: Includes a mechanical foot brake or an electronic DC injection
brake to stop the high-speed heavy drum within 5 seconds.
- Oil
Collection: A large 2-inch outlet at the bottom allows the extracted oil
to flow back into a collection tank for reuse, saving up to 15% in oil
costs.
Why the 20x20 Size
is "Professional Grade"
Small 12" or 14" hydros are for retail shops. The 20x20 inch size is designed for Commercial Production Lines because:
